2025 Kioti CS2520
Transmission:
Hydro
Horse Power:
24.5
Drive Type:
MFWD
CONTACT DEALER
DEALER INFO
AG Central COOP - Athens
920 CONGRESS PKWY N
ATHENS, TN 37303
DETAILS
| Price | Contact for Price |
| Year | 2025 |
| Make | Kioti |
| Model | CS2520 |
| Backhoe | No |
| Drive Type | MFWD |
| Front Fenders | No |
| Horse Power | 24.5 |
| Loader | Yes |
| New | New |
| Operator Station | No Cab |
| ROPS | Yes |
| Transmission | Hydro |
Description
| Engine Model 3C100LFH-U2 text4233687753 or4233687755 Engine Gross Power 24.5 hp (18.3 kW) Rated Speed 3,200 rpm No. of Cylinders 3 Fuel Type Diesel Displacement 61.5 cu in. (1,007 cc) Fuel Tank Capacity 6.7 gal. (25.5 L) Transmission Transmission Type Hydrostatic Main Gear Hydrostatic No. of Travel Speeds - Forward / Reverse Infinite, 2 Range Min. Travel Speed of Forward w/ Ag @ Engine rated speed 0 mph (0 km/h) Max. Travel Speed of Forward w/ Ag @ Engine rated speed 9.57 mph (15.4 km/h) Power Take-Off PTO Type Independent PTO Power 18.5 hp (13.9 kW) Rear PTO Speeds(1st) 540 rpm Mid PTO Speeds 2,200 rpm Brakes and Clutch Brakes Wet Multi Disc Dimensions w/ AG Tire Length w/ 3-point hitch 99.3 in. (2,523 mm) Width 45.9 in. (1,168 mm) Height From Top of the Highest Point 88 in. (2,226 mm) Wheelbase 55.1 in. (1,400 mm) Ground Clearance 6.4 in. (162 mm) Front Tread Ag Tires - Min 44.6 in. (1,133 mm) Rear Tread Ag Tires - Min 46 in. (1,168 mm) Turning Radius w/ Brake 8.2 ft. (2.54 m) Hydraulics Total Pump Flow 6.97 gpm (26.4 L/min) 3-Point Hitch Standard Category Category 1 Maximum Lifting Capacity (24”aft. of hitch) 700 lbs. (318 kg) Control Type Position Weight Weight w/ Ag Tires w/ ROPS 1,554 lbs. (705 kg) |
