| Model AJB9 1040-1, Aluminum, Pneumatic dry bulker, Interior ring,
Non-code trailer.
Code Non-code
Capacity 1040 cubic feet, 3 hopper
Compartments One
Shape Round with 45 degree discharge hoppers. Internal ring with
smooth exterior.
Shell Material Aluminum, 5454H32 barrel, end cone, and upper hopper
section.
Head Material Aluminum, .3125
Operating Pressure 25 PSI
Design Temperature 185 Degrees F.
Overall Length 42'-6"
Product Cement and Various other Dry Products; to be compatible with
the materials of construction.
Other Barrel Information
Material Finish Bright mill finish.
Construction
Front Aluminum extruded channel, bolted or integrated to center
frame.
Rear Aluminum extruded channel, bolted to center frame, small
cube trailers less than 1400 cube.
Center Aluminum extruded channel.
Struts Aluminum extruded struts, standard duty at both ends.
Product
Hauled: Cement
Hale Trailer Brake & Wheel
A012107-A012121
VINS: 123465-123477 & 123480-123481
Manhole 3 MM4120, 20” cast aluminum cover, six long lever aluminum
cam handles hold-downs with replaceable Nylon wear plates
and dual stainless steel safety retainers, 4" collar.
Gasket 3 White neoprene gasket in cover, non-toxic.
Manhole Hinge Location Manhole covers hinged to curbside of trailer.
Hose Carriers
Hose Carrier Aluminum tube 8" diameter x 21' long. Tube to be mounted to
the outer edge of brackets.
Hose Carrier Door 8" aluminum door, at rear. Door hinged at bottom.
* Carrier Location Mounted curbside
Lights and Wiring
Lights 12-volt, Truck-Lite LED grommet mount lights. Combination
center marker / turn signals, mounted on barrel frame.
* Wiring Plug-in style harness system.
Rear Lights Enclosed in Aluminum light boxes.
* Rear Lights 1 additional LED stop / turn / tail light. Total of 3 lights in each
box.
Outside lights are red with center light to be amber turn.
Extra Lights NONE.
Nose box Standard 7 way, J560 receptacle without circuit breakers.
Undercarriage
Upper 5th Wheel 5/16" Standard duty upper coupler with Heavy duty A.A.R.
style double hubbed kingpin.
standard duty
Paint Fifth wheel plate painted black.
Landing Gear Jost A440, 2-speed, load bearing, telescopic, with swivel type
sand shoe.
Bracing Stainless steel, with cross brace.
Crank location Crank handle located on roadside
Tire carrier None.
Suspension Hendrickson Intraax AAT23K, tandem axle with standard 49"
axle spacing. Hendrickson integrated axles.
Dump valve None
Hangers Galvanized hangers with soft coat applied to axle and trailing
arm. (Bolt-on suspensions with aluminum subframe only)
Bumper No bumper provided.
Under-ride Protection None (no under ride required, Wheels back exempt.)
Tire carrier None. No tire carrier installed.
Beam Inverted axle, humped up. NOTE: Axle diameter changes to 5"
with this option.
Track 71-1/2" track
Spindle OEM Standard P spindles (parallel) same inner and outer
bearing
Wheel seals OEM, standard w/ Hendrickson HXL
Hub & drums HXL3, READY TO ROLL, Duralite Hub with Centrifuse Drum.
Brakes OEM Standard
Anti-lock / Roll stability Wabco 4S/2M with "RSS-Plus", tandem axle roll stability
support system for air-ride suspension. Wired to auxiliary blue
circuit.
Brake chambers OEM type 30-30 long stroke parking-emergency spring brake.
Brake lining OEM Standard Extended service, non-asbestos
Slack adjusters OEM automatic slack adjuster.
Valves OEM Standard
Gladhands Gladhand, Phillips Quick release.
Air system One aluminum tank system. 2800 cu. in. each meeting FMVSS
121 D.O.T. specifications.
Emission Compliance NA
Wheels Original Equipment Manufacturer, 22.5 X 8.25 Aluminum
polished wheels
Tires Original Equipment Manufacturer,11R-22.5, Load Range G 14
Ply.
Front Aluminum, single contour, ribbed, front fender, each side.
Rear Aluminum, double contour, ribbed, rear fender, each side.
Mud flaps OEM Mudflaps
Hose hook
Hose hook Adjustable hose hook mou |
