Ironcraft 1912 Flex-Wing Cutter
CONTACT DEALER
DEALER INFO
County Equipment Co.
1901 WILLISBURG RD
LAWRENCEBURG, KY 40342
DETAILS
Price | Contact for Price |
Year | 0 |
Make | Ironcraft |
Model | 1912 Flex-Wing Cutter |
Condition | Not Specified |
Description
With its smooth top deck and spring suspension, this Flex-Wing Rotary Cutter is ideal for medium-duty applications such as weeds, grass, and brush up to 2” diameter. Designed for use with compact tractors of 35 hp minimum, the cutter requires only one hydraulic outlet. For its 144” cut width, the cutter uses three spindles with two free-swinging blades each, which reduce the shock of impact when a stationary object is contacted. Slip clutches protect the gearboxes and drivelines from damage. Standard equipment includes driveline shields, clutch shields, chain discharge shields and a safety tow chain. |
Other
Color Options Red Gray Green Orange Blue Specifications Recommended Minimum HP: 35 HP Hitch: Swivel Clevis Deck Thickness: 10 Gauge Deck Height: 11 in. Side Skirt Material: 3/16 in. Hinge Rods: 1 in. Suspension: Single Spring Outboard Gearbox PWR Rating: 75 HP Splitter Gearbox PWR Rating: 175 HP Gearbox Rpm: 540 RPM Blades: 1/2 in. X 3 in. w/ LIFT Blade Tip Speed: 15,657 FPM Blade Overlap: 6 in. Blade Carrier: 3/16 in. Formed Plate With 3/4 in. X 6 in. BAR Cut Width: 144 in. Overall Width: 151 in. Overall Length W/Wheel: 158 in. Tongue Weight: 759 lb. Overall Weight: 2630 lb. Cut Height: 1-1/2 in. - 12 in. Cutting Capacity: up to 2 in. Input Pto: Asae Cat 5 Constant Velocity Wing Drive PTO: Asae Cat 4 With Slip Clutch Skid Shoes: Replaceable Chain Shields: Single Row Chain Shields Standard Towing Safety Chain: Standard Gearbox Warranty: 5 Yr Limited Wheel Type: 5 LUG Standard Laminated - Used Aircraft Tires Optional |
